TP-LINK TL-MR3020 Portable 3G/3.75G/4G Wireless N Router

GENERAL

Type 3G Router
Installation Features Resource CD
Model Portable 3G/3.75G Wireless N Router
Part Number TL-MR3020
Controls WPS BUTTON , Mode Switch
In The Box TL-MR3020 Router, QIG, Power Adapter, USB Cable, Resource CD, Ethernet Cable
LED Indicator POWER, WIRELESS, WPS, LAN, WAN / INTERNET
Brand TP-LINK

OPERATING CONDITIONS

Operating Humidity Operating: 10 % - 90 % Non-condensing, Storage: 5 % - 90 % Non-condensing
Temperature Operating: 0DegC - 60DegC, Storage: -40DegC - 80DegC

POWER

Power Supply 5 V DC, 1 A
Power Consumption 5.4 W

SYSTEM REQUIREMENTS

Operating System Windows 7 and Above, Mac, Linux

SUPPORTED PROTOCOLS

Standard IEEE IEEE 802.11b/g/n, IEEE 802.3/3u

NETWORK FEATURES

Frequency 2.4 - 2.4835 GHz

SPEED

Wireless Speed 150 Mbps
LAN/WAN 10/100

CONNECTIVITY

USB USB 2.0
Antennae Internal
Number of LAN ports 1
Number of WAN ports 1
Number of USB Ports 1
WAN RJ-45
LAN RJ-45
Number of Antennae 1
Antennae Capacity On-Board

SECURITY

Encryption 152-bit WEP, 128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, TKIP, AES, ACL
Other Security Features DHCP Client List, Address Reservation, DHCP Server, Parental Control, Host List, Access Schedule, Rule Management, Virtual Server, Port Triggering, DMZ, UPnP Firewall DoS, NAT, SPI, MAC Address Filtering

ADDITIONAL FEATURES

Other Features
Mini USB Port: Power Supply, Port Forwarding: Virtual Server, Port Triggering, DMZ, UPnP, Supports Flow Statistics, Compatible Modems: Aircel: E1750C, EC303S (Huawei), Airtel: E1731 (Huawei), BSNL:...
SSID Support Yes
Certification CE Certification, FCC Certification, RoHS Certification
VPN PPTP, L2TP, IPSec Pass-through

DIMENSIONS

Height 22 mm
Width 74 mm
Depth 67 mm

WARRANTY

Service Type Carry In
Warranty Type Repair and Replacement
Covered in Warranty Manufacturing Defects
Domestic Term 3 Year
Not Covered in Warranty Physical Damages
Warranty Summary Physical Damage and Burn Out Cases are not entitled for Warranty
