KellyMed Automatic Syringe Pump Single Channel
Health Care & Medical » Medical Equipment » Medical Syringe Pump
Weight : 2.5 kg
Size : 314 x 167 x 140 MM
Syringe Size:
10, 20, 30, 50 ml
Applicable Syringe: 3 brands built-in (BD, B. Braun, Terumo), 2 brands for user-defined
Volume: 0.1-9999 ml <1000 ml in 0.1 ml increments =1000 mL in 1 ml increments
Flow Rate:
Syringe 10 ml: 0.1-400 ml/h
Syringe 20 ml: 0.1-600 ml/h
Syringe 30 ml: 0.1-900 ml/h
Syringe 50 ml: 0.1-1300 ml/h
<100 ml/h in 0.1 ml/h increments or decrements
=100 ml/h in 1 ml/h increments or decrements
Bolus Rate:
Syringe 10 ml: 400 ml/h
Syringe 20 ml: 600 ml/h
Syringe 30 ml: 900 ml/h
Syringe 50 ml: 1300 ml/h
Accuracy
±2% (mechanical accuracy =1%)
Infusion Modes:
Flow rate: ml/min, ml/h Time-based Body weight: mg/kg/min, mg/kg/h, ug/kg/min, ug/kg/h
KVO Rate:
0.1-1 ml/h in 0.1 ml/h increments
Alarms:
Occlusion, syringe drop off, near empty, end program, low battery, end battery, AC power off, motor malfunction, unattended pump, pressure sensor error, syringe installation error, syringe moved accidently
Additional Features:
Syringe identification, real-time shift totals, occlusion pressure release, bolus, mute button, automatic power switching, residue reminder, system memory
Occlusion Sensitivity:
High: 0.02-0.06 Mpa Medium: 0.06-0.09 Mpa
Low: 0.09-0.12 MPa
Power Supply:
AC 110 ~ 230 V , 50/60 Hz, 20 VA
Battery:
9.6±1.6 V, rechargeable
Battery Life: 5 hours at the 5 ml/h
Working Temperature:
5-40°C Relative Humidity:
20-90% Atmospheric Pressure:
860-1060 hpa
