Canon LV-WX300 Digital Projector
Projection lens
Zoom ratio / Focal length / F value :1.1x / 21.0 ? 23.1mm / F2.56 ? 2.8
Projection distance for 100? :3.2 ? 3.5m
Projection ratio (*1) :1.65:1 - 1.50:1
Operation :Zoom: manual, Focus: manual
Light source
Lamp type :Super-high pressure mercury lamp
Lamp power :190 / 160W (Lamp mode: normal / eco)
Images
Optical system :Time division colour extraction, sequential display
Brightness :3000 / 2100lm (Lamp mode: normal / eco)
Marginal lumination ratio :75%
Contrast ratio :2300:1
Amount of lens shift :50%, fixed
Electrical zoom (by length) :2x maximum
Keystone correction range :V ?30?
Image signal
Analog PC input: UXGA / SXGA+ / WXGA+ / FWXGA / WXGA / SXGA / XGA / SVGA / VGA / MAC
Digital PC input :UXGA / SXGA+ / WXGA+ / FWXGA / WXGA / SXGA / XGA / SVGA / VGA
Digital video input :1080p / 1080i / 720p / 576p / 480p
Component video input :1080p / 1080i / 720p / 576p / 576i / 480p / 480i
Video input :NTSC / PAL / SECAM / NTSC4.43 /P AL-M / PAL-N / PAL-60
S video input :NTSC / PAL / SECAM / NTSC4.43 /P AL-M / PAL-N / PAL-60
Terminal
Mini D-sub :15pin x 2 Analog RGB / Component video input
HDMI :Digital RGB / Digital video input
RCA :Composite video input
Mini DIN4 :S-video input
Mini Jack:Stereo audio input
Mini Jack :Stereo audio output
Dsub9 :RS-232C connection
RJ45 :100BASE-TX / 10BASE-T
USB type B :Service port
Mechanics
Adjustable feet: Front: 1, Rear: 1 (the angle of elevation of up to 6?)
Speaker: 10W monaural
Dimensions (W x H x D): W: 282mm, H: 114.5mm, D: 232mm (including protrusion)
W: 282mm, H: 91mm, D: 232mm (not including protrusion)
Weight :2.5kg (5.5lbs)
Noise :35 / 29dB
Others
Power supply :AC100V - 240V 50 / 60Hz
Power consumption :330W / 275W (Lamp mode: normal / eco)
